相信很多非人事不太容易区分仿威图机柜和普通机柜之间的差别，哪么今天小编为大家分析一下两者之边的区别。

It is believed that many non professional personnel are not easy to distinguish between imitation Rittal cabinets and ordinary cabinets. So today, I will analyze the differences between the two.

通俗讲就是仿照德国威图柜的产品，威图柜子对于表面处理要求很高防护等级也要求比别的高，但现在国内用的多是仿威图柜其主要原因是原装的威图柜太贵，仿威图柜相比便宜许多但其功能上来说都是一样的，仿威图柜其实就目前而言国内一般好一点一点的厂家都能生产。所以现在国内市场仿威图柜的市场占有早以超越真正的德国威图柜。

Generally speaking, it is a product that imitates German Rittal cabinets. Rittal cabinets require a high level of surface treatment and protection compared to other products. However, nowadays, most of the products used in China are imitation Rittal cabinets. The main reason is that the original Rittal cabinets are too expensive, and the imitation Rittal cabinets are much cheaper, but their functions are the same. In fact, at present, imitation Rittal cabinets are generally produced by better and more professional manufacturers in China. Therefore, the market share of imitation Rittal cabinets in the domestic market has already surpassed that of genuine German Rittal cabinets.

所以说国内大多数企业只要要求不是很严格，一般的话仿威图柜完完全全就能达到企业的需求。

Therefore, as long as the requirements of most domestic enterprises are not very strict, generally speaking, the imitation of Rittal cabinets can completely meet the needs of the enterprise.

1.威图柜从构造上可分为3大系列，ES柜（五折型材柜），PS柜（九折型材柜），TS柜（十六折型材柜），大的特色即是威图柜是选用型材构造构造，先将柜子的构造焊接好，然后顶板、底板、侧板、门板、装置板用螺丝固定在构造上这样的优点即是商品模块化构造运用便利；

1. Rittal cabinets can be divided into three major series in terms of structure: ES cabinet (50 fold profile cabinet), PS cabinet (9 fold profile cabinet), and TS cabinet (16 fold profile cabinet). The major feature is that Rittal cabinets are constructed using profile materials. Firstly, the structure of the cabinet is welded, and then the top plate, bottom plate, side plate, door panel, and device panel are fixed with screws. This advantage is that the modular structure of the commodity is convenient to use;

2.商品美观l机柜从工业品的运用和外观上都寻求完满的理念，从钣金构造规划和附件的调配运用也非常合理科学形成了标准化的配套规划；

2. The product is beautiful. The cabinet seeks a complete concept from the use and appearance of industrial products, and a standardized and scientific supporting plan has been formed from the planning of sheet metal structure and the allocation and application of accessories;

3.运用便利，内部的纵梁、立柱、横梁、走线条及自身的模塑化孔的规划使得用户装置都显得得心应手、便利自若；

3. Convenient use. The planning of internal longitudinal beams, columns, beams, routing lines, and their own molded holes makes the user's device seem handy and convenient;

4.健壮耐用、可靠威图柜构造构造使得构造稳固，单柜大可承重2000KG不惧装置任何粗笨器材；

4. Robust, durable, safe, and reliable Rittal cabinet construction ensures a stable structure, and a single cabinet can bear a load of 2000 KG without fear of installing any bulky equipment;

5.一起仿威图机柜从资料上别离碳钢和不锈钢料厚默许为门板2.0mm，装置板2.5mm，柜体1.5mm；

5. A simulated Rittal cabinet is separated from carbon steel and stainless steel in terms of data. The default thickness is 2.0mm for the door plate, 2.5mm for the device plate, and 1.5mm for the cabinet body;

6.碳钢的外表处理默许为喷塑处理喷塑前做磷化底涂处理，不锈钢的外表处理默许技术为拉丝处理。

6. The surface treatment of carbon steel implicitly refers to the phosphating primer treatment before plastic spraying, while the surface treatment of stainless steel implicitly refers to the wire drawing treatment.

仿威图机柜和普通机柜之间的区分方法就讲解到这里了，您对此有怎样的疑惑或者需求，就来我们网站http://www.tongyuhengcheng.com咨询了解吧！

This is the way to distinguish between imitation Rittal cabinets and ordinary cabinets. If you have any doubts or needs about this, please come to our website http://www.tongyuhengcheng.com  Consult and understand!
